Máy điện não 32 kênh KT88-3200

Máy điện não 32 kênh KT88-3200
103.730.000đ ♦ Mã sản phẩm: KT88-3200 ♦ Hãng sản xuất: Contec ♦ Xuất xứ: Trung Quốc ♦ Bảo hành: 12 tháng Đặt trước Online(Giữ hàng tại shop, không mua không sao)
Gọi đặt mua 024.3995.6682 hoặc 0912 194 775 (7h30 - 22h)

❖ Miễn phí vận chyển trong nội thành Hà Nội

❖ Tư vấn miễn phí 24/7 (cả dịp Lễ, Tết)

❖ Chúng tôi bảo hành sản phẩm tận nơi

❖Thanh toán khi nhận hàng bằng tiền mặt, thẻ ATM

Thông tin sản phẩm Máy điện não 32 kênh KT88-3200

Máy điện não kỹ thuật số truyền tải hoạt động điện sinh học của não thành hình ảnh có thể quan sát rõ ràng và thuận tiện. Thiết bị được chế tạo đặc biệt nên không gây thương tổn cho não và đầu bệnh nhân.

Máy điện não KT88-3200 phn tích đầy đủ và chính xác các hoạt động của não.

  • Giúp lảm nổi bật lên và nhận thấy rõ từng bộ phận trên điện não đồ.
  • Giúp bác sĩ nhận ra những đặc tính không rõ ràng, lê những đặc tính thường không được nhận ra đối với các máy điện não truyền thống.
  • Bộ khuếch đại EEG kỹ thuật số thông minh và tiên tiến nhất, tích hợp cả hộp điện cực, bộ khuếch đại, bộ lọc, bộ chuyển đổi tương tự-số.
  • Đánh dấu phân đoạn các nghiệm pháp bằng màu, giúp chuẩn đoán dể dàng và chính xác.
  • Sự truyền dẫn tín hiệu kỹ thuật số làm tăng khả năng chống nhiễu.
  • Hệ thống đạo trình chuẩn 10/20 quốc tế, Các chương trình EEG có thể lựa chọn bằng phần mềm.
  • Hỗ trợ giao tiếp USB, ghp nối với máy tính Laptop thành một hệ thống EEG xách tay.
  • Có thể điều khiển bộ kích thích thành ánh sáng tự động hoặc bằng tay.
  • Biên độ và tần số của EEG có thể đo đạc được.
  • Biến thế cách ly đặc biệt và hệ thống cáp quang đảm bảo an toàn.

Thông số kỹ thuật

Channel: 32 channels of EEG
• Sampling rate: 200 Hz
• A/D transformation: 12 bits
• Input impedance: ≥10MΩ
• Patient leak current: < 10µA
• Noise level: ≤5µVp-p
• CMRR: ≥90dB
• Magnification multiple: 10000
• Filter constant: all digital and free enactment
• Display speed(paper speed): 5, 10, 15, 30, 60, 120 mm/s
• Amplitude: 1, 1.5, 2, 3, 5, 7.5, 10, 12, 15, 20, 30, 50 mm/50µV
• Playback speed: 1 time, 2 times, 3 times, 10 times, 20 times, 40 times, 60 times
• 50Hz interference suppression: ≥30dB
• Safety type:Class II, type BF applied part Function Features
1. Standard 32 channels of EEG. Method of 10/20 electrodes placement under international
standard system, montages can be changed during collecting or replaying(such as
monopolar, bipolar or user-defined montages). Support different inactive electrode during
collecting(such as A1,A2,AA,AV,Bn,Cz).
2. Adopt bioelectricity amplifier for distilling brainwave, continuous record time can be up
to 24 hours, integrated full-automatic calibration system.
3. Powerful playback function: two playback modes(continuous and rolling) are optional,
amplitude and display speed are adjustable. The special subdividing time line divides the
waveform in one second into 5 parts, which is easy for doctors to look over the
waveform.
4. Multifunctional digital filter system provide different filter methods and window types,
and user can freely set low-pass, high-pass, band pass and band stop filter.
5. EEG signal clipping function, analyze and store any section of EEG wave, and select
several segments waveforms for automatically analyzing and distilling to different
parameters.
6. Electronic frequency ruler, convenient to measure the basic information of any appointed
EEG waveforms. With partial enlarging window, to accurately measure EEG period,
amplitude and frequency, and which can be adjusted according to personnel judgment.
7. Mark EEG wave under the events of opening eyes, closing eyes and flashing with
different colors, and user-defined events can be added, waveform color for evoked event
can also be set freely, ensures that the waveform in corresponding time can be rapidly
found by event name during case playback.
8. Powerful automatic analysis function, can carry through the power spectrum analysis and
pathologic wave detection for appointed waveform. Many graphs can be displayed in the
same screen, including kinds of BEAM, numerical BEAM, compressed spectrum graph,
trend graph, and so on.
9. Professional isolation transformer, dual power supply isolation system and optoelectronic
data transmission to ensure security. Use USB interface to transmit data which just need
to be inserted.
10. Multifunctional flash stimulator of USB interface, and frequency can be controlled
manually or automatically. A flash stimulation scheme can be set and performed in the
process of collection.
11. Perfect case management function, provides many means for research and quick statistic
information; convenient case export and import function, and stores with CD-RW disk,
which is easy for data research.
12. Integrative image and character report, report can be edited in mode and switched to
Word document.
13. Case files can be transformed into EDF and BDF data format, convenient for data
exchange, academic exchange and further analysis.
14. System parameters and display modes can be set as required, which meets different user’s
requirements.
15. Add marks and annotations to the waveform designated, which can rapidly find the
waveform in that time by marks.
16. Optional video function: USB camera is easy to install, convenient to use and exact to
record. With flexible playback function, which can browse the waveform of any time
along with the corresponding isochronous collected image.
17. SpO2 function which can view SpO2 value, pulse rate and SpO2 trend graph is optional. Accessories
• Standard accessories:
Forty EEG leads
Two EEG leads(ear electrode)
Two data lines
Thirty-five EEG electrodes
Two headgears
One flashlight
One flashlight power supply
One disk
One User Manual
One earth wire
Two aluminum blocks
• Optional accessories:
SpO2 module (one CMS-P SpO2 probe, one disk with software)
Video module(one softdog, one camera, one video software disk)
EEG bracket(tripod)
